Bundling Handkerchief tissue package Machine from China manufacturer - Guangzhou OK Machinery Manufacturing Co.,LTD

Bundling Handkerchief tissue package Machine

Payment Terms:	T/T,L/C,D/A,D/P,WU
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: OK-401

Production Capacity: 15 set/month

Delivery Date: 25 working days

Certification: CE

Brand Name: OK

Machine's Weight: 1500kg

Power: 380V50Hz

Means of Transport: Ocean,Land,Air

Packing: Wooden Case Package

Product Type: Others

Processing Type: Others

Speed: 15-25 bag/min

Compressed air pressure: 0.5Mpa

1.Handkerchief tissue bundling package
2.different package size
3.Easy adjust
4.PLC,Easy operation
5.One year grantee and all-life maintainan

Main Performance and structure features:

(1)This machine is improved form OK-301 handkerchief tissue packing machine, widely used in the automatic over-wrapping of various square Standard Type and Mini Type handkerchiefs (assembling) articles.

(2) It uses PLC human-machine interface controlling system, the servo engine controls the film dropping and the specification of the film dropping can be adjusted at any level.

(3) It have closed organic glass shield, platform of the machine and all parts contact with packing products are produced by stainless steel according to the sanitary standard.

(4) This machine, through few components replacement, is able to conduct the package of different handkerchiefs (namely different specification).

Model & Main technical parameters:

Model	Normal type ok-401	Larger type ok-401
Speed (bags/min)	15-25	40-50
Packing Arrangement Form	*23~27* *33~37*	*23~26* *33~36*
Outline dimension (mm)	*220011001650*	*320011001900*
Machine's weight (KW)	1500	3200
Compressed air pressure (Mpa)	0.5	0.5
Power	380V 50Hz	380V 50Hz
Power consumption (KW)	4.5	4.5
Packing Film	CPP, PE ,BOPP and other film sealed on both sides
